Edge Banding Machine – Si-6E
The SI-6E Edge Banding Machine is a fully automatic, high-performance edge bander engineered for precision edge finishing in modern furniture manufacturing. Equipped with advanced processing units, it delivers strong bonding, seamless trimming, smooth corner finishing, and superior polishing in a single pass, making it ideal for high-volume production of modular furniture, cabinets, and interior panels.
Key Features
- Fully automatic edge banding with high-speed operation
- Precision glue application for strong and uniform bonding
- Automatic end cutting for clean panel edges
- Rough and fine trimming for a flawless finish
- Corner rounding unit for smooth, professional edge profiles
- Scraping and buffing units for seamless, polished edges
- Compatible with PVC, ABS, veneer, melamine, and acrylic edge bands
- Digital control panel for easy operation and quick adjustments
- Heavy-duty construction for stable, vibration-free performance
- Suitable for MDF, plywood, particle board, block board, and laminated panels
- Designed for continuous production with high accuracy and reliability
- Installation & commissioning at your factory
- On-site operator training included
- 12-month warranty on the machine
- Spare parts stocked in India
- Installation & commissioning at your factory
- On-site operator training included
- 12-month warranty on the machine
- Spare parts stocked in India
SI-6E
|
Technical Specification |
6E |
5E |
7E |
8E |
Thickness of edge banding belt |
0.4-3mm |
0.4-3mm |
0.4-3mm |
0.4-3mm |
|---|---|---|---|---|
|
Height of edge banding belt |
--- |
--- |
--- |
--- |
|
Thickness of work piece |
10-50mm |
10-50mm |
10-50mm |
10-50mm |
|
Min. width of work piece |
50mm |
80mm |
50mm |
50mm |
|
Min. length of work piece |
40mm |
60mm |
60mm |
60mm |
|
Feeding speed |
13M/min |
0-13m/min |
12-20m/min |
12-20m/min |
|
Air pressure |
0.6-0.8Mpa |
0.6-0.8Mpa |
0.8MPa |
0.8MPa |
|
Total power |
11kW |
7.13kW |
12KW |
14KW |
|
Machine size |
3800*800*1410 mm |
2750x800x1260mm |
4000*800*1410 mm |
4200*850*1450 mm |
|
Weight |
1200kg |
1000kg |
1350kg |
1400kg |
|
Pre-milling motor power |
NA |
NA |
2*3 HP |
2*3 HP |
|
End cutting motor power |
2*0.5 HP |
2*0.5 HP |
2*0.5 HP |
2*0.5 HP |
|
Rough trimming motor power |
NA |
NA |
NA |
2*0.5 HP |
|
Fine trimming motor power |
2*0.5 HP |
2*0.5 HP |
2*0.5 HP |
2*0.5 HP |
|
Round cornering motor power |
NA |
NA |
2*0.5 HP |
2*1 HP |
|
Buffing motor power |
2*0.5 HP |
2*0.5 HP |
2*0.5 HP |
2*0.5 HP |
What every order includes
A machine is only as good as the support behind it. Each MJ270 is delivered as a commissioned, production-ready installation — not just a crate on your floor.
A machine is only as good as the support behind it. Each MJ270 is delivered as a commissioned, production-ready installation — not just a crate on your floor.
Delivery & positioning
Freight, unloading and machine placement coordinated to your factory layout.
Installation & commissioning
On-site setup, calibration and a test run before handover.
Operator training
Hands-on training so your team runs the machine confidently from day one.
Warranty & spare parts
12-month machine warranty with consumables and spares stocked in India.
Need Help Choosing the Right Machine?
Our team can help you select the ideal woodworking solution based on your production requirements, factory layout, material type, and budget. Get expert guidance before making your investment.
Our team can help you select the ideal woodworking solution based on your production requirements, factory layout, material type, and budget. Get expert guidance before making your investment.
From Inquiry to Installation
A clear, accountable process — so you always know the next step and who owns it.
From Inquiry to Installation
A clear, accountable process — so you always know the next step and who owns it.
Explore More
Other machines commonly ordered with this product.
Get In Touch
Request a Quote
FAQ’s
Frequently Asked Questions
Yes. We import directly from manufacturers in China, Taiwan and Europe — no middlemen involved.
Delivery timelines vary depending on the machine model and stock availability. Most standard machines are delivered within 4–8 weeks, while custom configurations may require additional time. Our team will provide an estimated delivery schedule during the quotation process.
Yes. Our experienced technicians visit your factory to handle machine installation, calibration, and commissioning, ensuring the equipment is ready for production.
Absolutely. We provide comprehensive operator training during installation, covering machine operation, maintenance procedures, safety guidelines, and best practices for maximum productivity.
Yes. We assist with factory layout and production flow planning to help optimize space utilization, improve workflow efficiency, and maximize machine performance.
We serve a wide range of industries, including furniture manufacturing, modular furniture production, interior fit-outs, woodworking workshops, panel processing facilities, cabinetry, and custom wood product manufacturers.
Yes. We can arrange live demonstrations, either at our showroom, customer sites, or through video demonstrations, so you can evaluate the machine’s performance before making a decision.
We offer flexible payment terms based on the order value and machine type. Our sales team will discuss suitable payment options during the quotation process.
Our technical experts assess your production requirements, factory space, output goals, and budget to recommend the most suitable machinery solution.
Yes. We maintain a stock of commonly required spare parts and consumables to minimize downtime and ensure quick support when needed.
